Description
- Parameters:
Code Displacement cm3/rev [in3/rev]
Max. Driving Speed RPM
Max. Driving Torgue*** Nm [lb-in]
Output kW [HP]
Max. Pressure bar [PSI]
Max. Oil Flow Ipm [GPM]
cont. int* cont. int** cont. int** cont. int** cont. int* PAP 22 22,15 [1.35] 3000 3400 123 [1090] 148 [1310] 30 [40.2] 35 [47] 350 [5080] 420 [6100] 64 [16.9] 82 [21.7] PAP 28 28,47 [1.74] 3000 3400 158 [1400] 190 [1680] 38 [51] 48 [64.4] 350 [5080] 420 [6100] 70 [18.5] 90 [23.8] * Intermitten speed (flow) is for pressure up to 150 [2200] bar [PSI]
** Intermitten load: the permissible values may occur for max. 10% of product lifetime.
*** Theoretical torque - General:
Min Speed RPM 500 Max Pressure in Drain Line bar [psi] 5 [70] Pressure fluid Mineral based- HLP(DIN 51524) or HM(ISO 6743/4) Temperature range, °C [°F] -40÷82 [-40÷180] Optimal Viscosity range, mm2/s [SUS] 12÷68 [70÷320] Filtration ISO code 18/16/13 (Min. recommended fluid filtration of 10 micron )
